Smart Cutter — FS / FC Series
Whole-domain software control with edge-walk-cut and common-line cutting AI — 80 m/min on 90 mm ply, tuned for automotive and industrial-material lines that need higher hold-down than the FE class.
- Bed footprint
- 5180 × (3035.5 / 3238.5 / 3441.5) × 2254 mm
- Weight
- 3,600 – 4,200 kg
- Total power
- 28 / 30 kW
- Edge-walk-cut
- Continuous gantry cut under feed
FS / FC is positioned for automotive and industrial-material multi-ply cutting. The spec sheet lists 25 kPa vacuum on the FS flagship (vs. FE's 23 kPa) and 28/30 kW total power for the heavier hold-down required by thick coverstock and technical layups. The FS / FC models share the same 5180 mm chassis: FS9 cuts 90 mm ply at 80 m/min, FS6 cuts 60 mm at 80 m/min, FC8 tunes to 50 m/min for thicker plies.
- Automotive coverstock and trim layups
- Technical textile and industrial nonwoven
- Heavy denim and canvas
- Home-textile cut floors
- Industrial-material processing
- Batch-production floors
Whole-domain edge-walk-cut
Software-controlled walk-and-cut adapts to piece size in real time and feeds under continuous vacuum — no re-positioning, no window waste, less fabric used.
Common-line cutting AI
Analyses two adjacent cut paths and automatically plans a shared cutting line, cutting it once without over-cutting or damaging pieces.
See the FS / FC Series up close
Tap any photo to enlarge. Configurations, working width and options vary by model — talk to an engineer for the build that fits your line.
Where FS / FC Series runs
Industries that pair with this system in production. Tap a card to see the full workflow and the favorable line-up that backs it.
Built for the cutting room
- Bed footprint
- 5180 × (3035.5 / 3238.5 / 3441.5) × 2254 mm
- Weight
- 3,600 – 4,200 kg
- Total power
- 28 / 30 kW
- Edge-walk-cut
- Continuous gantry cut under feed
- Common-line AI
- Auto-merge close paths into shared line
Model variants in one platform.
Each variant shares the platform vacuum, chassis and control system listed above — selection is by the per-model specs below.
| Spec | FS9 | FS6 | FC8 |
|---|---|---|---|
| Compressed ply height | 90 mm | 60 mm | 80 mm |
| Blade | 2.4 × 8.5 mm | 2 × 7 mm | 2.4 × 8.5 mm |
| Max cut speed | 80 m/min | 80 m/min | 50 m/min |
| Vacuum | 25 kPa | 25 kPa | 23 kPa |
| Avg. power draw | 12 kW | 12 kW | 10 kW |
Ready for a quote on the FS / FC Series?
Send us material, daily volume and throughput target for your FS / FC Series configuration. A favorable engineer returns a price within 24 hours — typically same business day.
